HOWO ZZ1257N5247A Truck & Special Vehicle Cargo Truck
Model:
ZZ1257N5247A
View All >
Category:
Truck & Special Vehicle
Product:
Cargo Truck
Brand Name:
HOWO
Dimension (mm):
7100x2300x2200
Operating weight (kg):
10t
Origin:
China
Min Order Quantity:
1 Unit
Delivery Time:
Summary
Rated Load Capacity:
10t
Engine Brand:
HOWO
Cargo Body Volume:
10-60m³
Cargo Body Dimensions:
8650x2300x2200
Engine Power:
336HP
Fuel Tank Capacity:
9.726L
Model:
WD615.69
Rated power:
336HP(247Kw/rpm)
Displacement:
9.726L
Specifications
Packaging & Shipping
Overall Dimensions (L×W×H):
7100x2300x2200
Overall Weight:
10t
Shipping Method:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Period:
10 days
Certificate:
ISO,ccc
Origin:
China
HS Code :
8429510000
Details

Product Overview

HW76 extend cab, one berth, with A/C all steel forward control, 55°hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, adjustable roof flap, with stereo radio/cassette recorder, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt.

Product descriptions from the supplier

Warning/Disclaimer

Compliance Reminder for Prohibited and Restricted productsView more

California Proposition 65 Consumer WarningView more

Product Paramenters


Typical truck modelZZ1257N4341WZZ1257N4641WZZ1257N5247AZZ1257N5847W
CabModelHW76
Type
EngineModelWD615.69WD615.47
Rated power336HP(247Kw/rpm)371HP(273Kw/rpm)
Displacement9.726L
Type6 cylinder in-line with water cooling, turbo-charging & inter cooling
Wheelbase4300+1400mm4600+1400mm5200+1400mm5800+1400mm
Cargo body size7100x2300x2200mm7650x2300x2200mm8650x2300x2200mm9500x2300x2200mm
ClutchSingle- plate dry diaphragm spring clutch, diameter 430(C) mm, hydraulically operating with air assistance
TransmissionSINOTRUK HW series 10/12/16 speed transmission, 10 forward and 2 reverse
Front axleSteering axle with double T-cross section HF7/HF9
Drive axlePressed axle housing, central single reduction ST16/MCY(Q)/HC16/AC16Ratio:3.93 4.42 4.8 5.73
ChassisFrame: U-profile parallel ladder type with section of 320×90×8 mm, all cold riveted cross members and reinforced subframeFront suspension: 9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizerRear suspension: 9+6 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizerSpare wheel carrier: with one spare wheelAluminum fuel tank: with 400 L fuel tank with locking fuel cap
SteeringGermany brand, hydraulic steering with power assistance
BrakesService brake: dual circuit compressed air brakeParking Brake(emergency brake): spring energy, compressed air operating on rear wheelsAuxiliary brake: engine exhaust brakeOption: ABS
Wheel & TypesRims: 8.0-20, 10 hole-steelTypes 11.00-20 tube;Option: 12.00-20 tube, 12.00R20 tube
ElectricsOperating voltage:24V, negative grounded; Starter: 24V, 5.4KWAlternator: 28V, 1540W; Batteries: 2×12, 165AhCigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp
