ZOOMLION RT100 Lifting Machinery Truck Crane
Model:
RT100
View All >
Category:
Lifting Machinery
Product:
Truck Crane
Brand Name:
ZOOMLION
Dimension (mm):
14247×3620×3960mm
Operating weight (kg):
100t
Origin:
Jiangsu, China
Min Order Quantity:
1 Unit
Delivery Time:
Summary
Max. Lifting Capacity:
100t
Max. Lifting Height:
45.6m
Main Boom Length:
78
Number of Axles:
5
Boom Sections:
4
Engine Brand:
CR
Exterior noise level:
≤88dB(A)
Max. travel speed:
≥80 km/h
Rated power/rpm:
390/1900 kW/(r/min)
Max. permissible weight:
54990 kg
Specifications
Packaging & Shipping
Overall Dimensions (L×W×H):
14247×3620×3960mm
Overall Weight:
100t
Shipping Method:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Period:
10 days
Certificate:
ISO,CE
Origin:
Jiangsu, China
HS Code :
CE
Details
Category ItemUnit Parameter
Dimensions Dimensions (Length×width×height)mm16225×3000×3995
Wheel basemm2650+1650+2900+1650
Track (Front/ Rear)mm2590
Front/ Rear overhangmm2660/2135
Front/ Rear extensionmm2325/255
WeightMax. permissible weightkg54990
Axle load1st axlekg11490
2nd axlekg12000
3rd axle kg12000
4th axlekg9900
5th axlekg9600
Rated power/rpmkW/(r/min)390/1900
Max. net power/rpmkW/(r/min)385/1900
Max. torque/rpmN.m/(r/min)2500/1000-1400
TravelMax. travel speedkm/h≥80
Min. travel speedkm/h≤5
Min. turning diameterm≤18.5
Min. turning diameter at boom tipm≤23
Min. ground clearancemm307
Approach angle°19
Departure angle°16
Braking distance (at 30 km/h )m≤10
Max. grade ability%≥60
Fuel consumption per 100 kmL70
NoiseExterior noise leveldB(A)≤88
Noise level at seated positiondB(A)≤90
Main     Max. total rated lifting capacityt160*
Min. rated working radiusm2.5
Turning radius at turntable tailCounterweight mm5110
Auxiliary winchmm4960
Max. load momentBase boomkN.m5145
Fully-extended boomkN.m2115
Fully-extended boom + JibkN.m1940
Outrigger span Longitudinalm8.99
Lateralm7.9
Hoist heightBase boomm14.9
Fully-extended boomm76.9
Fully-extended boom + Jibm103.1
Boom lengthBase boomm14.4
Fully-extended boomm78
Fully-extended boom + Jibm107.4
Jib offset angle°0、15、30
Working speedBoom raising times≤60
Boom fully extended times≤760
Max. slewing speedr/min≥1.5
Outrigger extending and retracting timeOutrigger beamRetractings≤40
Extendings≤40
Outrigger jackRetractings≤60
Extendings≤90
Hoisting speed (single line, 4th layer, no load)Main winchm/min≥135
Auxiliary winchm/min≥90
NoiseExterior noise leveldB(A)≤110
Noise level at seated positiondB(A)≤85
